Variant Code

  1. Check for improper installation of PCM (ECM & TCM)/ESC.
  2. Connect scantool to Data Link Connector(DLC).
  3. Ignition "ON".
  4. Go in Anti-Lock brake system (figure 1).
  5. Perform variant code.
  6. Disconnect scantool.
  7. Ignition "OFF" and then ignition "ON". Go to "COMPONENT INSPECTION " Procedure.
Fig 1: Scan Tool Display - Current Data
G04883893Courtesy of KIA MOTORS AMERICA, INC.
