Circuit Diagram

Fig 1: Immobilizer Control System - Circuit Diagram
G00488735Courtesy of KIA MOTORS AMERICA, INC.
Fig 2: Immobilizer Control System - Connector Views
G04885186Courtesy of KIA MOTORS AMERICA, INC.
