Repair and Diagnosis
>>
Accessories & Equipment
>>
Entertainment Systems
>>
Audio System
>>
Multimedia Jack
>>
Troubleshooting
>>
Chart 7
July 1:
So it begins
. Don't worry, this is not in the correct legal jurisdiction!
Chart 7
Fig 1: Multimedia Jack Troubleshooting Flow Chart 7
Courtesy of KIA MOTORS AMERICA, INC.
