Trunk Open Switch

  1. Check for continuity between the trunk open switch terminals.
    G12921348Courtesy of KIA MOTORS AMERICA, INC.
  2. If continuity is not as specified, inspect the switch.
G12921349Courtesy of KIA MOTORS AMERICA, INC.
