Repair Procedures: Removal
WARNING: This page is about a different car, the 2018 Kia Optima. However, it is still accessible from the selected car via links, so may be relevant.
- Turn the ignition switch OFF and disconnect the battery (-) terminal.
- Disconnect the mass air flow sensor connector (A) and the installation clamp (B).
- Remove the mass air flow sensor (C).
Courtesy of KIA MOTORS AMERICA, INC.
