Circuit Inspection
| Inspection Condition | (+) Probe | (-) Probe | Specification | ||
|---|---|---|---|---|---|
| Connector | Terminal | Connector | Terminal | ||
|
FPCM connector | 10 (power) | Chassis ground | - | B+ |
| FPCM connector | 4 (ground) | Chassis ground | - | Approx. 0V | |
Good
- Go to "Component Inspection " procedure.
No Good
- Repair as necessary and then go to "Verification of Repair " procedure.
