Component Inspection

Inspection Condition Inspection Procedure Reference
  1. Ignition "ON".
  1. Connect KDS/GDS to Data Link Connector(DLC).
  2. Monitor "Diagnostic Trouble Codes(DTC)" with KDS/GDS.
 figure below.
G12580385Courtesy of KIA MOTORS AMERICA, INC.
  1. Accelerator pedal is depressed
  2. Accelerator pedal is not depressed

    Good

    No Good

    • Carefully re-do this troubleshooting guide steps.
    • If no problems were found with the circuits or connectors, replace the Accelerator Pedal Sensor and go to "Verification of Repair " procedure.
