Multi-Display Controller: Components

WARNING: This page is about a different car, the 2006 Lexus RX 400h. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Exploded View Of Multi-Display Controller Components With Torque Specifications
G04115639Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
