Components [09/2014 - ]

Fig 1: Thermostat Replacement Components With Torque Specifications
GTY496722Courtesy of © TOYOTA, LICENSE AGREEMENT TMS1002
*1 NO. 1 ENGINE UNDER COVER ASSEMBLY *2 OIL THERMOSTAT HOUSING ASSEMBLY
*3 OIL COOLER ASSEMBLY *4 O-RING
*5 OIL COOLER UNION BOLT *6 GASKET
*7 OIL PAN DRAIN PLUG *8 OIL FILLER CAP SUB-ASSEMBLY
N.m (kgf/cm, ft.lbf): Specified torque • Non-reusable part
