Section 312 (Engine Cooling System): Specifications
WARNING: This page is about a different car, the 2003 Lincoln Navigator and 2003 Ford Expedition. However, it is still accessible from the selected car via links, so may be relevant.
Identifying General Specifications (1 Of 2)
| Item | Specification |
|---|---|
| Cooling System Capacity | |
| 4.6L | 19.0 L (20.1 quarts) |
| 4.6L - with aux. rear heat | 21.0 L (22.2 quarts) |
| 5.4L | 21.0 L (22.2 quarts) |
| 5.4L - with aux. rear heat | 23.0 L (24.3 quarts) |
| Coolant Type | |
| Motorcraft Premium Engine Coolant VC-4-A (in Oregon VC-5, in Canada CXC-10 or equivalenta | ESE-M97B44-A (Green color) |
| Motorcraft Premium Gold Engine Coolant VC-7-A (in Oregon VC-7-B) or equivalentab | WSS-M97B51-A1 (Yellow color) |
| Other Chemicals | |
| Motorcraft Cooling System Flush VC-1 | ESR-M14P7-A |
| Premium Long Life Grease XG-1-C | ESA-M1C75-B |
| Cooling System Stop Leak Pellets VC-6 | ESE-M99B37-B5 except as noted in ES-F6SE-19A511-AA |
| Cooling System Pressure Test Specifications | |
| Radiator test pressure | 152 kPa (22 psi) |
| Radiator Cap Pressure Test Specifications | |
| Pressure relief opening pressure | 110 kPa (16 psi) |
Identifying General Specifications (2 Of 2)
| Item | Specification |
|---|---|
| Thermostat Opening Temperatures | |
| Starts to open °C (°F) | 87-91 (188-195) |
| Fully open °C (°F) | 100 (212) |
- Use the same type coolant that was drained from the cooling system. Do not mix coolant types.
- The addition of Motorcraft Cooling System Stop Leak Pellets, VC-6, darkens Motorcraft Premium Gold Engine Coolant from yellow to golden tan.
