WARNING: This page is about a different car, the 2003 Lincoln Aviator. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Connector Terminals Of Rear Auxiliary Control C3198B
Courtesy of FORD MOTOR CO.
NOTE:
All measurements taken with the front auxiliary controls in the rear position.
Fig 2: Connector Terminals Of Rear Auxiliary Control C3198B Legend
