Torque Specifications

Lower Intake:

Exhaust Manifold:

Upper Engine:

Install the cylinder head bolts. Tighten in the sequence shown in two steps.

Tightening torque:
Step 1 68.9-81.0 Nm (51-59 ft-lb)
Step 2 108.5-122.0 Nm (80-89 ft-lb)

Timing Components:

Auxiliary Shaft:

Lower Engine:

Flex Plate (A/T) Torque/Sequence:

Flywheel (M/T) Torque/Sequence:
