Condenser Removal/Installation

WARNING: This page is about a different car, the 2003 Mazda 6. However, it is still accessible from the selected car via links, so may be relevant.

Disconnect the negative battery cable.
Remove the rear package trim.
Remove in the order indicated.

Fig 1: Identifying Condenser Components
Courtesy of MAZDA MOTORS CORP.

Fig 2: Condenser Removal Sequence
Courtesy of MAZDA MOTORS CORP.
Install in the reverse order of removal.
