Front Stabilizer Removal/Installation: Notes

WARNING: This page is about a different car, the 2005 Mazda 6. However, it is still accessible from the selected car via links, so may be relevant.

Remove the front crossmember component. (See FRONT CROSSMEMBER REMOVAL/INSTALLATION .)
Remove in the order indicated in the table.

Fig 1: Removing Front Crossmember Component (Torque Specs)
Courtesy of MAZDA MOTORS CORP.
Install in the reverse order of removal.
Inspect the front wheel alignment. (See FRONT WHEEL ALIGNMENT .)
