Room Fuse Installation

WARNING: This page is about a different car, the 2005 Mazda MX-5 Miata. However, it is still accessible from the selected car via links, so may be relevant.

NOTE:

When the ROOM fuse is burnt or removed, the malfunction indicator lamp illuminates. If the ROOM fuse is replaced or installed with the ignition switch at the ON position, the malfunction indicator lamp will continue to illuminate.

Turn the ignition switch to the LOCK position.
Install the ROOM fuse.

Fig 1: Identifying Room Fuse
Courtesy of MAZDA MOTORS CORP.
