Pilot Bearing Installation Note
- Install the pilot bearing using the corresponding 20mm {0.79 in} side of a Snap-on brand millimeter size bushing driver set A160M adapter A160M7 (20-22mm{0.79-0.86 in}) or substitution tool.
Substitution tool
Outer diameter: 21 mm {0.83 in}
Inner diameter: 19 mm {0.75 in}
