3 position

Terminal: 6P (+) ↔ body ground (-)
Oscilloscope setting: 2 V/DIV (Y), 1 ms/DIV (X), DC range

Fig 1: Sensitivity Adjustment Volume (3 Position)

G06942408

Courtesy of MAZDA MOTORS CORP.
