No. 1 Door Cannot Be Locked/Unlocked By Advanced Key [Advanced Keyless Entry And Push Button Start System]: Notes
NO. 1 DOOR CANNOT BE LOCKED/UNLOCKED BY ADVANCED KEY [ADVANCED KEYLESS ENTRY AND PUSH BUTTON START SYSTEM] DESCRIPTION & POSSIBLE CAUSES
| 1 |
Door cannot be locked/unlocked by transmitter (electrical key button) |
| DESCRIPTION |
- Cannot door lock and/or unlock with transmitter (electrical key button)
|
| POSSIBLE CAUSE |
- Malfunction in transmitter (electrical key button) battery or transmitter (electrical key button)
- Malfunction in keyless control module
- Malfunction in keyless receiver
- Malfunction in BCM
- Malfunction indoor switch or trunk lid switch
- Open or short circuit in wiring between trunk lid latch switch and BCM
- Open or short circuit in wiring harness door switch and BCM
- Malfunction in door lock actuator
- Open or short circuit in wiring between door lock actuator and BCM
- Open or short circuit in wiring between keyless control module and BCM
- Poor connection of connector, terminal damage
- Wrong usage
- The after-market electrical parts are interfering with the keyless entry system
|
|
|
