DTC B10D3:23 [Advanced Keyless Entry And Push Button Start System]: Notes

DTC DETECTION CONDITION AND POSSIBLE CAUSES

DETECTION CONDITION	Detect request switch (RF) ON signal while driving
POSSIBLE CAUSE	Connector or terminal malfunctioning Short to ground in wiring harness between front front outer handle (RH) terminal D and keyless control module terminal 3U Request switch (RF) malfunction Keyless control module malfunction
