DTC P0615:12 [Advanced Keyless Entry And Push Button Start System]: Notes

DTC DETECTION CONDITION AND POSSIBLE CAUSES

DESCRIPTION	Short to power supply in starter circuit
DETECTION CONDITION	Detect that the voltage of starter relay is higher than the specification. Feedback voltage of starter relay output circuit higher than 6 V is detected under the following conditions: IG1 relay output circuit is not active Clutch is depressed
POSSIBLE CAUSE	Starter relay malfunction Connector or terminal malfunction Short to power supply in related wiring harness Keyless control module malfunction
