DTC B113E:11 [Advanced Keyless Entry And Push Button Start System]: Notes

DETECTION CONDITION	Trunk lid opener switch (vehicle exterior) circuit voltage less than 1 V  is detected for 1 s  , while ignition switch is ON
POSSIBLE CAUSE	Connector or terminal malfunction Trunk lid opener switch (vehicle exterior) malfunction Short to ground in wiring harness between trunk lid opener switch (vehicle exterior) terminal B (vehicles with rear mount camera), F (vehicles without rear mount camera) and keyless control module terminal 3G Short to ground in wiring harness between trunk lid opener switch (vehicle exterior) terminal B (vehicles with rear mount camera), F (vehicles without rear mount camera) and BCM terminal 6E BCM malfunction Keyless control module malfunction
