Quick Diagnostic Chart [Exterior Open Function]

Fig 1: Quick Diagnostic Chart (Exterior Open Function)

Courtesy of MAZDA MOTORS CORP.

NOTE:

• The exterior open function does not operate when the following conditions are met.
  • Any door or trunk lid is open.
  • The key is inserted in the steering lock.
  • The start knob is not in the LOCK position.
• The auto-open/close function (the exterior open function) does not operate if the power window system initial setting procedure has been reset.
• Depending on the temperature and battery conditions, the window may reverse on rare occasions.
