Keyless Beeper Removal/Installation

WARNING: This page is about a different car, the 2014 Mazda 6. However, it is still accessible from the selected car via links, so may be relevant.
  1. Disconnect the negative battery cable. (See NEGATIVE BATTERY CABLE DISCONNECTION/CONNECTION .)
  2. Remove the cowl grille. (See COWL GRILLE REMOVAL/INSTALLATION .)
  3. Disconnect the connector.
    Fig 1: Identifying Keyless Beeper Connector
    G09787820Courtesy of MAZDA MOTORS CORP.
  4. Pull the keyless beeper in the direction of the arrow (2) shown in the figure while pressing the keyless beeper tab in the direction of the arrow (1) shown in the figure, detach the keyless beeper tab and bracket, and then remove the keyless beeper from the bracket.
  5. Install in the reverse order of removal.
    Fig 2: Pulling Keyless Beeper
    G09787821Courtesy of MAZDA MOTORS CORP.
