| DETECTION CONDITION |
- The condition has continued for 2 s
in which difference in intake air temperature measured by the IAT sensor No. 1 and boost air temperature sensor is 30 °C {54 ° F} or more
and difference in intake air temperature measured by boost air temperature sensor and IAT sensor No. 2 is 30 °C {54 °F} or more.
MONITORING CONDITIONS
- Period vehicle being left: 6 h or more
- Battery voltage: 8 V or more
- Within 20 s
after engine start
- The following DTCs are not detected:
- Boost air temperature sensor: P007C-00:, P007D-00:
- IAT sensor No. 1: P0112-00:, P0113-00:
- IAT sensor No. 2: P0097-00:, P0098-00:
Diagnostic support note
- This is a continuous monitor (CCM).
- The check engine light illuminates if the PCM detects the above malfunction condition during the first drive cycle.
- FREEZE FRAME DATA/Snapshot data is available.
- DTC is stored in the PCM memory.
|
