Coil Spring Installation Note

WARNING: This page is about a different car, the 2016 Mazda CX-3. However, it is still accessible from the selected car via links, so may be relevant.

Compress the coil spring using the SST .

Fig 1: Compressing Coil Spring
Courtesy of MAZDA MOTORS CORP.
Install the coil spring with the end of the coil spring seated on the stopper of the upper spring seat.

Fig 2: Installing Coil Spring
Courtesy of MAZDA MOTORS CORP.
