Coil Spring Installation Note

  1. Compress the coil spring using the SST.
    G11438130Courtesy of MAZDA MOTORS CORP.
  2. Install the coil spring with the end of the coil spring seated on the stopper of the upper spring seat.
    G11438131Courtesy of MAZDA MOTORS CORP.
