Remove Front Console: Notes

  1. Remove using the procedure shown in the figure.
    G16708784Courtesy of MAZDA MOTORS CORP.
    PART NAME DESCRIPTION

    Step Part name
    1 Front console
    (See FRONT CONSOLE REMOVAL NOTE ).
