Selector Lever Bezel: Removal

  1. With the vehicle in NEUTRAL, position it on a hoist. For additional information, refer to JACKING AND LIFTING article.
  2. Remove the PRNDL trim ring.
    3. Fig 1: PRNDL Trim Ring
    GF0017855Courtesy of FORD MOTOR CO.
  3. Remove the upper console panel.
    4. Fig 2: Upper Console Panel
    GF0017856Courtesy of FORD MOTOR CO.
  4. Slide the lower shift knob bezel downward.
    5. Fig 3: Lower Shift Knob Bezel
    GF0017857Courtesy of FORD MOTOR CO.
  5. Remove the bolt and lift up on the shift knob to remove.
    6. Fig 4: Shift Knob Bolt
    GF0017858Courtesy of FORD MOTOR CO.
  6. Remove the lower shift knob bezel.
    7. Fig 5: Lower Shift Knob Bezel
    GF0017859Courtesy of FORD MOTOR CO.
  7. Disconnect the light bulb from the PRNDL bezel.
    8. Fig 6: Light Bulb At PRNDL Bezel
    GF0017860Courtesy of FORD MOTOR CO.
  8. Release the 4 locking tabs and remove the PRNDL bezel assembly.
    9. Fig 7: Identifying Locking Tabs
    GF0017861Courtesy of FORD MOTOR CO.
