62 11... Configuration Of Instrument Cluster

WARNING: This page is about a different car, the 2002 BMW M Roadster, 2002 BMW M Coupe, 2001 BMW M Roadster, and 2001 BMW M Coupe. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Exploded View Of Instrument Cluster

Courtesy of BMW OF NORTH AMERICA, INC.

Shown from left to right:

Floor panel

Display system

Instrument panel
