62 11 ... Configuration of instrument cluster

WARNING: This page is about a different car, the 2002 BMW Z3 and 2001 BMW Z3. However, it is still accessible from the selected car via links, so may be relevant.

Shown from left to right:

Floor panel.

Display system.

Instrument panel.

Fig 1: Identifying Configuration Of Instrument Cluster
G03179365Courtesy of BMW OF NORTH AMERICA, INC.
