Rear Suspension - Evolution: Description: Notes

A trailing arm type multi-link suspension has been used for the rear suspension. See Fig 1 . In contrast to the trailing arm multi-link system used on the Lancer, the Lancer Evolution uses a newly developed multi-link system built on a double wishbone base to achieve superior handling stability.

Fig 1: Identifying Rear Shock Absorber Components

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
