General Description
>>
Shift Pattern Control
>>
< Downshift Pattern >
April 5, 2026:
LEMON Manuals is launched!
Read the announcement.
< Downshift Pattern >
Fig 1: Identifying Shift Pattern Control (Downshift Pattern)
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
