Disassembly And Assembly: Notes

WARNING: This page is about a different car, the 2005 Mitsubishi Montero. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Disassembling/Assembling Brake Disc
G02495437Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
