4.7L Engine

Fig 1: Identifying Throttle Position Sensor And IAC Motor

Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.

The 3-wire Throttle Position Sensor (TPS) is mounted on the throttle body (2) and is connected to the throttle blade shaft.
