Pre-removal operation
- Air Cleaner Intake Duct and Air Intake Hose Removal
(Refer to AIR CLEANER
).
- Battery and Battery Tray Removal
(Refer to BATTERY
).
- Engine Room Under Cover Front A, B Removal
(Refer to UNDER COVER
).
|
Post-installation operation
- Engine Room Under Cover Front A, B Installation
(Refer to UNDER COVER
).
- Battery and Battery Tray Installation
(Refer to BATTERY
).
- Air Cleaner Intake Duct and Air Intake Hose Installation
(Refer to AIR CLEANER
).
|
