Rear Refrigeration System
WARNING:
This page is about a different car, the 2005 Nissan Quest. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Rear Refrigeration System Replacement Components - With Torque Specifications
Courtesy of NISSAN MOTOR CO., U.S.A.
