Diagnostic Procedure

CHECK GROUND CONNECTIONS
1. Turn ignition switch OFF.
2. Loosen and retighten two ground screws on the body. Refer to GROUND INSPECTION .

  Fig 1: Locating Ground Screws
  Courtesy of NISSAN MOTOR CO., U.S.A.
OK or NG
- OK : GO TO 2.
- NG : Repair or replace ground connections.
CHECK ENGINE COOLANT TEMPERATURE SENSOR
Refer to "COMPONENT INSPECTION ".

OK or NG
- OK : GO TO 3.
- NG : Replace engine coolant temperature sensor.
CHECK THERMOSTAT OPERATION
When the engine is cooled [lower than 75°C (167°F)], grasp lower radiator hose and confirm the engine coolant does not flow.

OK or NG
- OK : GO TO 4.
- NG : Repair or replace thermostat. Refer to "THERMOSTAT AND THERMOSTAT HOUSING ".
CHECK INTERMITTENT INCIDENT
Perform "TROUBLE DIAGNOSIS FOR INTERMITTENT INCIDENT ".
- : INSPECTION END
