Keyless Entry Transmitter: Service and Repair

Programming Receiver Connector:

One (1) or two (2) transmitters may be programmed. When two (2) transmitters are to be programmed, they must be programmed during the same program sequence (see procedure).

1. Connect a fused jumper from the Keyless Entry Programming Connector to ground. The Keyless Entry Module will cycle all the Door Lock Motors once.

2. Press any button on the transmitter once. In response, the Keyless Entry Module will cycle all the Door Lock Motors once.

3. If a second transmitter is to be programmed, press any button on the second transmitter once. In response, the Keyless Entry Module will cycle all the Door Lock Motors once.

4. Remove the fused jumper from the Keyless Programming Connector.
