Window Regulator Motor: Installation

  1. Install motor to regulator using 3/16" rivets. See Fig 1 .
  2. Install screw and nut locking sector gear in a fixed position.
  3. Install the regulator. See WINDOW REGULATOR  .
Fig 1: Identifying Window Motor On Window Regulator
G00127210Courtesy of GENERAL MOTORS CORP.
