Wiper Switch: Service and Repair

Fig. 4 Housing and wiper switch removal & installation. Standard steering column:

Fig. 5 Cover and wiper switch removal & installation. Tilt steering column:

WINDSHIELD
1. Remove turn signal switch as outlined under ``Turn Signal Switch, Replace'' procedure.
2. Refer to Figs. 4 and 5 for wiper switch replacement.

REAR WINDOW
1. Disconnect battery ground cable.
2. Remove left hand trim panel, then right side switch trim cover.
3. Remove switch attaching screws, then switch.
4. Reverse procedure to install.
