Installation Procedure
WARNING: This page is about a different car, the 2002 GMC Savana Special, 2002 GMC Savana Camper Special, 2002 GMC Savana, and 2002 Chevrolet Chevy Express. However, it is still accessible from the selected car via links, so may be relevant.
CAUTION:
Use the correct fastener in the correct location. Replacement fasteners must be the correct part number for that application. Fasteners requiring replacement or fasteners requiring the use of thread locking compound or sealant are identified in the service procedure. Do not use paints, lubricants, or corrosion inhibitors on fasteners or fastener joint surfaces unless specified. These coatings affect fastener torque and joint clamping force and may damage the fastener. Use the correct tightening sequence and specifications when installing fasteners in order to avoid damage to parts and systems.
- Install the coolant temperature sensor to the cylinder head.
Tighten
Tighten the sensor to 20 N.m (15 ft lbs).
- Snap the coolant temperature sensor electrical connector to the intake manifold bracket.
- Connect the coolant temperature sensor electrical connector to the wiring harness at the intake manifold.
- Install the engine cover.
- Fill the cooling system with coolant. Refer to Draining and Filling Cooling System .
- Start the engine. After the engine reached normal operating temperature, check for coolant leaks.
