Removal Procedure

WARNING: This page is about a different car, the 2002 GMC Savana Special, 2002 GMC Savana Camper Special, 2002 GMC Savana, and 2002 Chevrolet Chevy Express. However, it is still accessible from the selected car via links, so may be relevant.
  1. Remove the front trim plate. Refer to Door Trim Plate Replacement (Manual Windows)  or Door Trim Plate Replacement (Power Windows)  or Door Trim Plate Replacement (Side/Rear Door)  .
  2. Remove the electrical connector (3) from the power window switch.
  3. Release the clip from the front door trim plate (1) in order to remove the escutcheon from the trim plate (1).
  4. Release the tabs on the power window switch (10) in order to remove the power window switch (10) from the escutcheon.
Fig 1: Removing Power Window Switch
G01736948Courtesy of GENERAL MOTORS CORP.
