Installation Procedure

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2003 GMC Yukon XL, 2003 GMC Yukon, 2003 Chevrolet Tahoe, 2003 Chevrolet Suburban, and 2003 Chevrolet Avalanche. However, it is still accessible from the selected car via links, so may be relevant.

Mount the microphone (1) to the overhead console at the left rear corner of the overhead console.

Fig 1: Installing OnStar Microphone

Courtesy of GENERAL MOTORS CORP.

Clip the microphone bracket (1) to the overhead console.
Connect the microphone connector (2) to the mating 2-way connector.
Reinstall the overhead console. Refer to CONSOLE REPLACEMENT - OVERHEAD in Interior Trim.
