Installation Procedure

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2003 GMC Yukon XL, 2003 GMC Yukon, 2003 Chevrolet Tahoe, 2003 Chevrolet Suburban, and 2003 Chevrolet Avalanche. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the new sensor grille to the headliner.
  2. Install the inside air temperature sensor to the headliner and sensor grille.
    Fig 1: Installing Inside Air Temperature Sensor To Headliner
    G01454865Courtesy of GENERAL MOTORS CORP.
  3. Connect the electrical connector to the inside air temperature sensor.
  4. Install the left sunshade. Refer to GARNISH MOLDING REPLACEMENT - CENTER PILLAR in INTERIOR TRIM
  5. Install the left center pillar garnish molding. Refer to GARNISH MOLDING REPLACEMENT - CENTER PILLAR in INTERIOR TRIM .
  6. Install the left center assist handle. Refer to ASSIST HANDLE REPLACEMENT - REAR in Interior TrimINTERIOR TRIM .
  7. Install the left windshield garnish molding. Refer to GARNISH MOLDING REPLACEMENT - WINDSHIELD PILLAR in INTERIOR TRIM .
    Fig 2: Connecting Electrical Connector To Inside Air Temperature Sensor
    G01454866Courtesy of GENERAL MOTORS CORP.
