Output Control
WARNING: This page is about a different car, the 2003 GMC Sierra, 2003 GMC Cab & Chassis Sierra, 2003 Chevrolet Silverado, and 2003 Chevrolet Cab & Chassis Silverado. However, it is still accessible from the selected car via links, so may be relevant.
Dimming Level: The scan tool displays the duty cycle of the pulse width modulated (PWM) signal distributed by the BCM to the interior lighting circuits. The scan tool displays 0 percent when the interior lamps illumination is OFF. The scan tool displays 100 percent when the interior lamp illumination is at full intensity.
Daytime Running lamps: The scan tool displays the commanded state of the daytime running lamps (DRL). The scan tool displays On when the BCM illuminates the DRL.
Park Lamp Relay: The scan tool displays the commanded state of the park lamp relay. The scan tool displays On when the BCM allows the park lamp relay to go to ground to activate the park lamps.
