Removal Procedure

WARNING: This page is about a different car, the 2003 GMC Sonoma, 2003 GMC Jimmy, 2003 Chevrolet S10 Pickup, and 2003 Chevrolet Blazer. However, it is still accessible from the selected car via links, so may be relevant.

Important: Replace the CD and plastic bin as a whole assembly. Removing and installing the screws that attach the CD changer to the plastic bin may cause the CD changer to perform improperly.

Open the armrest (5) on the center console to reveal the remote CD changer assembly.
Remove the 2 front screws (1) and the rear screw (3) that attach the CD changer assembly to the center console.
Pull the CD changer assembly vertically out of the center console
Disconnect the electrical connector to the CD changer (4).

Fig 1: Remote CD Player
Courtesy of GENERAL MOTORS CORP.
