Scan Tool Data Definitions
WARNING: This page is about a different car, the 2003 Chevrolet Corvette. However, it is still accessible from the selected car via links, so may be relevant.
Battery Volts: The scan tool displays the current state of the battery in volts.
Horn Relay Feedback: The scan tool displays Active or Inactive. When the BCM energizes the horn relay, the scan tool will display Active. When the BCM de-energizes the horn relay, the scan tool will display Inactive.
