Installation Procedure

WARNING: This page is about a different car, the 2003 Chevrolet Corvette. However, it is still accessible from the selected car via links, so may be relevant.

Place the spacer on the dash panel stud.
Position the foot rest over the spacer.
NOTE: Refer to FASTENER NOTICE in Cautions and Notices.
Install the nut to the stud.
Tighten

Tighten the foot rest nut to 10 N.m (89 lb in).
Install the nut to the side rail stud.
Tighten

Tighten the foot rest nut to 10 N.m (89 lb in).

Fig 1: Foot Rest
Courtesy of GENERAL MOTORS CORP.
