System Specifications

Compressor type 7 SB 16
Refrigerant quantity 850 g refrigerant R 134a
Refrigerant oil in the compressor 195 ± 15 cubic cm ND 8







NOTE: When installing the refrigerant lines, the screw connections and the O-rings must be wetted with refrigerant oil.


The refrigerant oil must be disposed of as special-category waste.
