LED (Light Emitting Diode)
WARNING: This page is about a different car, the 2002 Saab 9-3. However, it is still accessible from the selected car via links, so may be relevant.
Courtesy of SAAB-SCANIA OF AMERICA, INC. LED (LIGHT EMITTING DIODE) TECHNICAL DATA
| Location |
In the center of the dashboard |
| Color |
Red |
| Power supply |
Pin No. 2 |
| Ground |
Pin No. 1 |
| Current limit from electronic control module |
20 mA |
